This factory service manual covers Zetor models 4712, 4718, 5711, 5718, 5745, 5748, 6711, 6718, 6745, and 6748. These robust agricultural tractors, primarily manufactured in Brno, Czechoslovakia, represent a significant era of Zetor's development, known for their durability and utilitarian design in demanding environments. The vehicles are typically powered by naturally aspirated diesel engines from the Zetor 52xx/62xx series, featuring inline 4 or 6-cylinder configurations, and are equipped with manual transmissions, often including a torque multiplier option. Their engineering emphasizes reliability, making them essential workhorses for agricultural and industrial applications.
This comprehensive manual provides detailed information for owners, mechanics, and technicians. It covers a wide array of systems including general maintenance, engine components (cooling, fuel, lubrication, cylinder head, valve gear, crank mechanism), powertrain (clutch, gearbox, torque multiplier, portals, front driving axles), braking systems (hydraulic, hand, pneumatic), suspension and steering, and electrical equipment. The manual includes step-by-step repair and maintenance procedures, diagnostic troubleshooting guides, specifications, and essential information on assembly tools, ensuring the longevity and optimal performance of your Zetor tractor.
ZETOR FACTORY SERVICE MANUAL
FOR ZETOR MODELS:
4712
4718
5711
5718
5745
5748
6711
6718
6745
6748
SECTIONS INCLUDE:
1. General hints for removal & re-fit,
2. Specifications,
3. Hood,
4. Cooling System,
5. Fuel System,
6. Lubrication System,
7. Cylinder Head,
8. Valve Gear,
9. Crank Mechanism,
10. Twin-purpose Clutch,
11. Compressor,
12. Gearbox,
13. Torque Multiplier,
14. Synchro-mesh Coupling,
15. Main Transmission Housing,
16. Portals,
17. Hydraulic Brakes,
18. Hand Brake,
19. Front Axle,
20. Sprung Extensions,
21. Front Driving Axle (Z 5745, Z 5748),
22. Front Driving Axle (Z 6745, Z 6748).
23. Ball-type Steering Mechanism,
24, Electrical Equipment,
25. Steering Booster,
26. Steering Damper,
27. Suspension,
28. Belt-pulley,
29. Safety Cab,
30. Hot-air Heating,
31. Seat,
32. Pneumatic Brakes,
33. Tyres,
34. Hydraulic Lift Unit,
35. List of Shaft Seals & Bearings,
36. List of Assembly Tools
