The Komatsu FB Series forklift trucks, including the FB14RW-1R, FB16RW-1R, FB20RW-1R, and FB25RW-1R models, represent Komatsu's line of electric counterbalance forklifts designed for efficiency and performance in various industrial environments. Built with Komatsu's legacy of durability and engineering excellence, these industrial forklift trucks offer rated load capacities ranging from 1400 kg to 2500 kg. They are engineered to provide reliable material handling solutions, featuring electric powertrains and advanced control systems for optimal operation.
This Service Repair Workshop Manual provides comprehensive, in-depth information for the repair, servicing, and technical maintenance of the Komatsu FB 14-25 RW-1R series forklift trucks. It covers a wide range of systems, including electrical, hydraulic, lift group, electric motor, and power steering, with detailed explanations, diagrams, and troubleshooting guides. The manual is designed to empower owners, mechanics, and technicians to perform maintenance and repairs effectively, reducing reliance on external service and ensuring the forklift remains in optimal working condition.
This is the COMPLETE Service Repair Manual for the Komatsu FB14RW-1R, FB16RW-1R, FB20RW-1R, FB25RW-1R Forklift Truck. This manual contains deep information about maintaining, assembly, disassembly and servicing your Komatsu FB14RW-1R, FB16RW-1R, FB20RW-1R, FB25RW-1R Forklift Truck.
This Manual contains information and data to this model. has specs, diagrams, and actual real photo illustrations, and schemes, which give you complete step by step operations on repair, servicing, technical maintenance & troubleshooting procedures for your machine. this manual offers full information you need for repair your machine. the information in this manual will enable you to find trouble and to understand how to repair and maintain your machine without going into service. all pages are printable, so run off what you need and take it with you into the garage or workshop.
Models Covered :
Komatsu FB 14 RW-1R
Komatsu FB 16 RW-1R
Komatsu FB 20 RW-1R
Komatsu FB 25 RW-1R
Table of Contents :
General Rules
Introduction
Lift Group
Hydraulic system
Electric motor
Electrical system
Power steering
Optionals
Programming
Accelerator pedal autosensing
FB 14-25 RW-1R from serial number F24519P00001
Electrical diagrams
=======================================================
